Capacities
Max. capacity 7716 lbs
Max. lifting height 19 ft 11 in
Max. outreach 10 ft 6 in
Reach at max. height 2 ft
Breakout force with bucket 5402 daN
Weight and dimensions
Unladen weight (with forks) 16768 lbs
Ground clearance 1 ft 4 in
Wheelbase 8 ft 6 in
Overall length to carriage (with hitch) 15 ft 3 in
Front overhang 3 ft 8 in
Overall width 7 ft 10 in
Overall cab width 3 ft 1 in
Overall height 7 ft 10 in
Tilt-down angle 134 °
Tilt-up angle 12 °
External turning radius (over tyres) 12 ft 4 in
Standard tyres Alliance - A580 - 460/70 R24 159A8
Drive wheels (front / rear) 2 / 2
Steering wheels (front / rear) 2 / 2
Performances
Lifting 5.8 s
Lowering 4.5 s
Extension 3.7 s
Retraction 3.8 s
Crowd 2.5 s
Dump 2.2 s
Engine
Engine brand Deutz
Engine norm Stage V
Engine model TCD 3.6 L4
Number of cylinders - Capacity of cylinders 4 - 220.96 in³
I.C. Engine power rating / Power (kW) 129 Hp / 95 kW
Max. torque / Engine rotation 500 Nm @1600 rpm
Drawbar pull (Laden) 8500 daN
Reversible fan Standard
Engine cooling system 4 radiators (water + intercooler + hydraulic oil + transmission oil)
