Servo-hydraulic press MA-01

laminationrollerPLC-controlled

1. Using the most advanced power drive mode, two permanent magnet synchronous motors drive two hard helical gear reducers to drive two rolls through drum tooth couplings. The electronic control part mainly adopts PLC and display touch screen control, and the stable production efficiency can reach 120m/min, Max.150m/min. 2. Pressure method: servo hydraulic pressurization, cylinder down; Roll joint adjustment mode: servo motor drives the middle oblique iron automatic adjustment, left and right sides can be adjusted separately, automatic pressure compensation device, hydraulic pressure displacement mode rolling force up to Max: 8200±0.1KN (≈836±0.1 tons), pressure control accuracy ≤± 0.1T, roll thickness accuracy in this mode ≤± 2μm, Max±0.8 μm. 3. Effective roll width of roll surface: 500-1400mm (adjusted according to the width of the pole piece). 4. The main engine supporting unwinding, winding, front expansion, back extension, front stretching, rear stretching, cutting edge dust removal, dust suction, double-row imported scraper clearing device, scale control belt platform, vibration damping mechanism can realize continuous rolling production. The main machine is equipped with a convenient roll disassembly device, which is convenient for more convenient and quick disassembly and replacement of rolls during equipment maintenance.
