Modular fiber optic distribution panel TSC UTCG

Outputs all time signals simultaneously on each of four fiberoptic outputs The Universal Time Code Generator (UTCG) receives multiple inputs and transmits a digital signal containing both time and frequency information on a single optical fiber for extremely high quality. The Universal Time Code Generator (UTCG) is a state-of-the art multiplexer that receives multiple inputs, including a frequency reference (required), 1PPS Sync signal (optional), and IRIG-B time code (optional) while simultaneously outputting all timing, RF, and time code on a single fiber to one or more Time Code Translators (TCTs) at remote locations. Fiberoptic transmission for high quality Because fiberoptic cable carries the time code to the TCT, the signal is of extremely high quality. There are no ground loops, crosstalk, or attenuation. No matter how many or what type of timing signals are needed at a remote location, only a single fiber pair is ever required. One fiber carries all timing signals to the TCT while the other optional fiber returns status information to the UTCG. Enormous Capacity 400 remote users can be supported with a single UTCG.
