Compressed air filter HG, HP series
cartridgehigh-pressurehigh-performance

compressed air filter
compressed air filter
compressed air filter
compressed air filter
compressed air filter
Add to favorites
Compare this product


Characteristics

Designed for
compressed air
Filtration element
cartridge
Applications
high-pressure
Other characteristics
high-performance
Filtration size

Min.: 0.01 µm

Max.: 5 µm

Operating pressure

50 bar, 350 bar (725.189 psi)

Flow

Min.: 71 m³/h (2,507.341 ft³/h)

Max.: 4,200 m³/h (148,321.6 ft³/h)

Description

HIGH PRESSURE COMPRESSED AIR FILTERS Features Mikropor manufactures a line of High Performance Compressed Air Filters, Moisture Separators in two different ranges; 50 bar range made of Aluminium. No welding, strong and reliable design. 350 bar range made of Steel. No welding and designed for reliability at very high pressure applications. Anodised Aluminium Design with High Performance Mikropor High Pressure Range Compressed Air Filters are NO-weld design. These Filters are built with ample wall thickness and as a result are extremely robust. In-house high pressure test facilities assure the performance. All inner and outer surfaces of 50 bar Aluminium design Filters are Anodised, where 350 bar Carbon Steel design Filters are epoxy electro powder coated.
