Bottle checkweigher 9616

for cylindersfor containerscontrol line

DYNAMIC WEIGHT CONTROL LINE FOR CYLINDERS UP TO 25L. Composed of: • A weight controller made entirely of stainless steel, with tapestry bands • It will consist of electronic equipment with a color touch screen to indicate the different parameters (average weight, total weight, number of rejected containers, etc. .). • Internal card with 6 inputs and 12 configurable outputs • USB port to store data on a pen drive. • Motorized input sequencer tape 400mm long x 300mm wide with guides. Motors with Driver to vary the speed. • Motorized belt with 50kg HBM load cell, 500mm long x 300mm wide. Motors with Driver to vary the speed. • Line stop and alarm system with luminous acoustic beacon for alarm signal. • Weighing functions: .- Static and dynamic weighing, with management of a photocell to detect the bottle. .- Dynamic weighing with two photocells, START/STOP type. .- Static and dynamic weighing without photocell. • Tolerance verification: .- Through article file, with programming of 3 tolerance thresholds, .- Programmable weight thresholds (minimum/maximum) with article file. .- Weight thresholds (minimum/maximum), quick introduction. .- Calculation and printing of statistics and standard deviation of the weighings carried out. .- Static or dynamic tape auto-zero functions. • Load cell description: SP4MC6MR/50Kg .- Single-platen load cell .-Nominal capacity: 50 kg .- Minimum division value: 2 g .-Precision class according to OIML R60: C6MR .-Maximum platform size: .- 450 x 450 mm according to OIML R76 .-Material: aluminum .-Protection class according to IEC 529: IP67 .-Cable type: .-shielded round cable, 6 cores, .-PVC coating .-Cable length: 3 m .-Connector: CE 100F26-6
