Swing door SUPERCLEAN

stainless steelindoorfor the food industry

Designed and manufactured by Moreschi to achieve even more extreme performance. Structure in stainless steel and special textured sheets, give high sealing characteristics at differential pressures up to 50Pa. Designed to meet the needs of hospitals, health care rooms, intensive care units, immune deficiency therapy, neonatal, aerospace, pharmaceutical, cosmetics, biotechnology, fine chemistry, electronics, semiconductors, micro-mechanisms, nanotechnology, optics and food. TECHNICAL PRODUCT INFORMATION Curtain: Antistatic fabric with FDA approval. Standard colours (similar RAL): Grey (7038), Blue (5005). The lower plinth is made of AISI 304 stainless steel sheet with satin finish and sealing gasket. Motorization: High efficiency gearmotor unit integrated in the door structure. Nominal speed up to 1 m/sec. Control unit with inverter also integrated in the structure that allows programming the movement of the curtain with acceleration and braking ramps and speed control. Safety: Photocell barriers Fields of application with temperatures between +4° C and +40° C Air permeability with pressure of of 50 Pa < 6 m³/m²*h EN12426 220V single-phase power supply CE marking EN13241-1 Optionals: Antistatic sky blue (5015) smooth antistatic sheeting Viewer with wide-angle camera Window section h.500mm Construction with UL components UPS SPECIFICATIONS Designed with motor and control unit integrated in the structure, they are positioned with reduced installation space and greater cleanliness in maintenance and cleanroom environments. COLORATIONS Standard colours (RAL similar): Grey (7038) antistatic, Blue (5005) antistatic.
