1. X.YWorking Area: 2000*6000mm
2. Lathe Structure:Whole 10mm Cast Iron
3. Transmission way: XYZ axis: Rack and Pinion
4. Guide Way: PMI Linear Square Rai l(Imported from Taiwan)
5. Max Idling Speed:18m/min
6. Spindle: 3.2kw water cooling spindle
7. Spindle Rotate Speed:0-24000RPM
8. Inverter:Fuling Inverter
9. Servo and driver: leadshine stepper motor and driver
10. Operating System: with singnal control cabinet(without computer) , NC studio control system, Breakpoint memory enable the machine to continue the unfinished work after work shift or accidents, such as tool breaking.
11.Working-Holding:T-slot Splint aluminium working table, easy to fix different size materials.
12. Cut 20mm acrylic speed can be 10m/mins, aluminium / copper speed can be 2-3m/mins etc.
13. Precision photoelectric switch, high precision, can engrave 1mm small letter
