CNC drilling machine NCB612

high precisioncompactrail

High technology compact machine making possible to drill holes on 6 sides, groove top and bottom, route shapes in one process without necessary of turning panel. Continuous working for various batch sizes and patterns to fit complex production. High accuracy and processing effective, basically no complaints. Long guiding rail with dual clampers for fast processing work of various work pieces. Easy production management due to self-recording function. Automatic detection of panel size reducing man made mistakes. Adjustment of panel position by best compensation automatically to suit furniture assembly process. Open port for international popular software, compatible with many file formats like xml, mpr etc. Choosing from powered or simple roller conveyor for feeding in and out of panel to form a production line based on requirements. Panel length 250-2400mm Panel width 30-1200mm Panel thickness 10-50mm Max speed 135/135/75/30m/min Main spindle power 3.5kw×2 Max rotation speed 18000rpm Upper vert.drill 12 Upper vert. drill X direction：2×2 Y direction：2×2 Lower vert.drill 10 Rotation speed 4000rpm Dust collector Top dust collector φ150mm Bottom dust collector φ125mm Total power 18kw Overall dimension 5546×2910×2100mm Net weight 3500kg
