Infrared detector SH-2001-WAD

infrared detector
infrared detector
Add to favorites
Compare this product


Detected entity
infrared, gas, multi-gas
Gas type
ammonia, nitrogen, NO, H2, H2S, oxygen, O2, ozone, benzene, Cl2, flammable gas, toxic gas, CH4, CO, SO2, HCl, formaldehyde, CO2, VOC, for LPG
suction type, electrochemical
Other characteristics
high-sensitivity, compact, fixed, wall-mounted, with digital display, with replaceable sensor, with data logging, with built-in pump, with alarm, two-sensor, multi-sensor, LEL
for indoor use, laboratory, for clean rooms, industrial


Multi gas detector SH-2001-WAD - multi gas detector A suction type detector ideal for indoor use. Monitors up to 2 different gases in line. Ideal to distinguish between leakage of CO and IPA! Features: Ideal for cleanroom applications Integrated alarm handling Available with pyrolyzer Optional Profibus-DP, Modbus and SIMS communication Data acquisition by Incontrol Software Also available for scrubber applications Available for almost all gasses (toxic, combustible etc) Almost all combination of sensors possible Possible application; Tools, Environmental, MFC box Indication of detectable gasses; Cl2, ClO2, H2S, HCN, HCl, SO2, SO3, COCl2, HF, O3, Br2, I2, O2, CO, CO2, F2, CiF3, H2, CH3COOH, NO, NO2, HNO3, HCHO, C2H5OH, IPA, ETo, Po, NH3, CH3NH2, C2H5NH2, (CH3)2NH, (CH3)2N, (C2H5)3N N2H4, TDMAT, C2H4(NH2)2, Si(C2H5O)4, Si(C2H5O)4, HBr, H2Se, C2H2, C2H4, C3H6, SiCL4, SiH2CL2, POCl3, SnCl4, SbCl5, BCl3, SiF4, BF3, WF6, ASF3, PF5, AsF6, MoF6, PH3, AsH3, SiH4, B2H6, Al(CH3)2H, NF3, HCFC, CCl4, CHCl3, CH3Cl, CH2Cl2, ChCl;CCl2, CCl:CCl2, C2H5Cl, C3H5Cl, C3H5ClO, C3H5Cl, EDC, VCM, CH3Br, Ch3I, SF6, N2O, HFC, PFC, C4F6, GeH4, AN, (CH3)3SiH, (CH3O)3SIH, HC, CH4, C2H2, C4H10, C6H12, C8H18, C10H16, CH3COC2H5, C6H6, C6H5CH3, C6H4(CH3)2, C6H5C2H5 Should you gas to detect not be included, please contact us.
