Water filter SUPERDRUM

drumpressuregravity

SuperDrum is an automatically self-cleaning micro-screen filter designed for removal of suspended solids. SuperDrum is available in a variety of sizes and designs so you can find one to suit your needs. SuperDrum filters water through the machine by gravity and has a low pressure drop. In addition SuperDrum also has a low energy cost, which together with a proven design provides a low life-cycle cost. PRODUCT INFROMATION Proven robust construction The SuperDrum filter comprises several filter panels mounted around a rotating inlet drum and provides a simple yet robust solution for the removal of particles. SuperDrum is available in five different sizes: 0.6 m, 0.8 m, 1.2 m, 1.6 m and 2.0 m in diameter and provides up to 22.5 m2 net filter surface per machine. The woven filter fabric, with a density down to 10 microns, sits firmly on the filter panels and is uniformly tensioned to maximise fabric life and minimise the number of attachment points. A proven and robust design that provides high efficiency filtration with minimum pressure drop. Main applications • Food industry • Waste water • Primary treatment of waste water • Fish farming • Untreated water screening • Pre-filtering • Paper and pulp How SuperDrum works The water to be filtered enters the drum via the inlet and gravitates out through the filter in the drum outer edges. The particles are separated and stick to the inside of the filter. When the water level in the drum reaches a preset level, the drum starts to rotate and the filter backflush starts. By means of high-pressure washing SuperDrum uses the filtered water to remove the accumulated particles and deposit them in the pan.
