Forward travel vibratory plate C-2D

for excavatorsremote-controlled

Hoses are routed out of the back of the compactor, safely away from the trench wall. Integrated flow control and pressure regulating valves protect the motor from excessive flow and pressure. Heavy-duty, direct drive gear motors. Durable rubber shock mounts to isolate vibration. Self-aligning, double row, spherical roller bearings with heavy duty steel roller cage. Internally routed hoses for maximum protection. Oil splash lubrication, eliminates routine greasing. Model NPK - C-2D Excavator weight (ton) - 2.5 – 5.5 Cycles per min (c/min) - 2400 Working pressure (MPa) - 10.5 – 14 Oil flow (l/min) - 42 – 49 Dimensions base plate (mm) - 320×635
