Semi-automatic assembly machine AS 221 GA

for industrial applicationsadjustable

Thermal break profile semi-automatic assembly machine 8 driven dise shafts with automatic adjustment of the dise closing load depending on any slight profile deformation. Horizontal simultaneous movement of dises with décimal adjustment indi-cated on display. Pair of adjustable compensation dises for profiles horizontal linearity correction. Quick change upper and lower sliding rollers made of not abrasive material, which allow to support also not perfectly straight profiles thanks to the structural flexibility. Upper rollers are provided with both a mechanical and an automatic load adjustment accordingto anysmall deformation ofthe profile. Vertical simultaneous movement of upper rollers with décimal adjustment indicated on positioner. Adjustable compensation rollers for profiles vertical linearity correction. Idle conveyor rollers for easier profile loading. Servo-assisted front protection gâte with safety device on opening. Flap door on the rear side with safety device on opening. Direction of movement changeable only at low speed. Electrical and pneumatic setting, including emergency stop System for nection to loading and unloading roller conveyors. Standard equipment - Standard lower roller kit in polymer for profile support - Standard upper roller kit iin polymer for profile calibration - Set-up drawings for each profile - Installation, operation and maintenance manual - Service spanners
