5-axis CNC machining center MILLAC 800VHverticalhigh-productivityhigh-rigidity
Add to favorites
Compare this product
Characteristics
- Number of axes
- 5-axis
- Spindle orientation
- vertical
- Other characteristics
- high-speed, high-productivity, high-rigidity
- X travel
1,020 mm
(40 in)- Y travel
1,020 mm
(40 in)- Z travel
1,020 mm
(40 in)- Rotational speed
Min.: 100 rpm
(628 rad.min-1)Max.: 10,000 rpm
(62,832 rad.min-1)- Power
18.5 kW, 22 kW
(25.15 hp, 29.91 hp)- Work feed X-axis
30,000 mm/min
(20 in/s)- Work feed Y-axis
30,000 mm/min
(20 in/s)- Work feed Z-axis
30,000 mm/min
(20 in/s)- Table load capacity
1,000 kg
(2,205 lb)
Description
This 5-axis, multi-plane machining center combines high speed with high rigidity. A box-type bed and a rectangular/wide sliding surface provide the machine with its highly rigid structure. Our MILLAC 800VH employs large ball screws and highly rigid supports with pre-tension to ensure stability in accuracy. The multi-face machining capability allows for the machining of complex workpieces in one setup. This improves part accuracy by eliminating the setup errors inherent in re-fixturing the part. In addition, the rotary-type 2APC is a standard feature to reduce setup time and to increase productivity.
