Data connector PCC-SMD series

data connector
data connector
Add to favorites
Compare this product


Product applications
for RTD sensors, for thermocouples, temperature probe, for high-temperature applications, data logger
Other characteristics
miniature, built-in


•Produced on a reel for use with pick-and-place machines •Used in pairs for miniature 2-pin thermocouple connectors •1 contact per pin connection great for RTD''s and Thermistors •Perfect for handheld thermometers and dataloggers •Universal calibration provides great accuracy when paired with integrated cold junction compensation •Made of nickel-plated beryllium copper, boasting a high operating temperature range (even higher range on high temp PCB) •Patent-pending design features reverse polarity protection for error-proof assembly The PCC-SMD connector from OMEGA is perfect for bringing Thermocouple, RTD, and/or Thermistor probes to high volume production printed circuit boards. Take advantage of the built-in cold junction compensation features of your chosen Analog to Digital Converter (ADC). The flat bottoms of these connectors have a superior design that thermally couples them to the circuit board for ideal cold-junction compensation. These SMT populated connectors can be used with any Thermocouple Calibration and are designed for low-cost, high-volume production. They also feature a patent-pending asymmetric design that prevents connectors from being plugged in backwards. Connectors come conveniently packaged in 13” diameter tape-and-reel.
