Thermocouple wire TF series

thermocouple wire
thermocouple wire
Add to favorites
Compare this product


Description

Fine Insulated Thermocouple Wire • Insulated thermocouple wired with a single Strand • Extruded PFA • IEC or ANSI Colour Coded • Excellent in a Vacuum • Non-Flammable • Available in 15m/50ft. and 30m/100ft. Reels for Convenient Small Quantity Needs • Order a "Matched Pair" • Wire Sizes Available 0.003" (0.07 mm) 0.005" (0.12 mm) 0.010" (0.25 mm) 0.015" (0.38 mm) 0.020" (0.51 mm) 0.032" (0.81 mm) Description OMEGA's fine gauge single strand thermocouple wire is available in 15, 30, 150 and 300 metre (50, 100, 500 and 1000 ft.) reels. Each reel represents a single conductor for a particular thermocouple type. Wire diameters range from 0.07mm(0.003") up to 0.81mm(0.032"). The wire is covered by extruded PFA insulation. The insulation thickness is 0.08 mm (3 mil) for wire sizes equal to and less than 0.25 mm (0.010"). For wire sizes greater than 0.25 mm (0.010"), the insulation thickness is 0.2 mm (8 mil).
