Absolute pressure transducer PXM4 series
vacuumpiezoresistivestrain gauge

absolute pressure transducer
absolute pressure transducer
absolute pressure transducer
Add to favorites
Compare this product


Characteristics

Pressure type
absolute, vacuum
Technology
strain gauge, silicon, piezoresistive
Output
4-20 mA
Mounting
threaded
Material
stainless steel
Protection level
intrinsically safe, EMC, IP65, IP67
Other characteristics
precision
Applications
process
Process temperature

Max.: 121 °C (250 °F)

Min.: -45 °C (-49 °F)

Pressure range

Max.: 350,000 mbar (5,076.32 psi)

Min.: 25 mbar (0.36 psi)

Precision

0.08 %

Long-term stability

0.1 %

Description

High (0.08%) Accuracy Pressure Transducers • Pressure transducer with 5-Point Traceable Calibration Certificate Included • G 1/4 (1/4" BSPP) Thread Standard • 0 to 100 mV, 0 to 10 Vdc, or 4 to 20 mA Outputs • Gauge, Compound Gauge, Absolute, Vacuum and Barometric Pressure Ranges Available • Welded Stainless Steel Construction • 316 Stainless Steel Wetted Parts • Premium Temperature Performance • Broad Compensated Temperature Range • Rugged Design, with Secondary Containment Description Omega's high accuracy piezoresistive pressure transducers have a proven record in high performance commercial and aerospace applications for over 25 years. The piezoresistive process uses strain gauges molecularly embedded into a highly stable silicon wafer. The silicon wafer is diced into individual die which each contain a full strain gauge bridge. The die is mounted in a sealed chamber protected from the environment by glass to metal seals and a stainless steel diaphragm. A small volume of silicone oil transfers the pressure from the diaphragm to the strain bridge. The construction provides a very rugged transducer with exceptional accuracy, stability and thermal effects. A unique design ruggedizes the transducers by providing secondary fluid containment in the event of a diaphragm rupture. During our production process, automated test equipment performs pressure and temperature cycling on 100% of the PXM409 series transducers. The transducers are then calibrated using extremely high accuracy standards and a 5-point traceable calibration certificate is included with each transducer.
