Beam expander BAM25 series

1.75X Aspheric Beam Expander, 12.4mm Input Aperture, 1064nm Design Wavelength As a member of the Precision Beam Tuning Offering, this 1.75X Beam Expander consists of a completely diffraction-limited aspheric lens, guaranteed by an original Asphericon certificate. These parts are disigned to becombined with other members of the Beam Tuning family to create a beam expansion of up to 32-times and numerous other beam modifications. Name:1.75X Aspheric Beam Expander, 12.4mm Input Aperture, 1064nm Design Wavelength Weight:0.0450kgs Guide:- Remark:- Attention:- Design wavelength:1064nm Item Returns:This item can be returned Input Diameter:12.4mm Output Diameter:22.5mm Tube Diameter φ:D30mm Tube Thread:M28x0.75 Tube Length:34.8mm Tube Material:Aluminum Lens Material:Fused Silica Coating:1000-1060nm, Ravg≤0.4%, AOI=0° Laser damage threshold:12 J/cm², 100 Hz, 6 ns, 532 nm 2.00X Aspheric Beam Expander, 10.6mm Input Aperture, 1064nm Design Wavelength As a member of the Precision Beam Tuning Offering, this 2.00X Beam Expander consists of a completely diffraction-limited aspheric lens, guaranteed by an original Asphericon certificate.These parts are disigned to becombined with other members of the Beam Tuning family to create a beam expansion of up to 32-times and numerous other beam modifications. Name:2.00X Aspheric Beam Expander, 10.6mm Input Aperture, 1064nm Design Wavelength Weight:0.0480kgs Guide:- Remark:- Attention:- Design wavelength:1064nm Item Returns:This item can be returned Input Diameter:10.6mm Output Diameter:22.5mm Tube Diameter φ:D30mm Tube Thread:M28x0.75 Tube Length:34.8mm Tube Material:Aluminum
