Steady indicator light O72

LEDdust-proofoil-resistant

Product overview
The 2025 Otennlux O72 IP69K 24 V 3-color 70 mm LED indicator features a smooth 70 mm dome providing uniform illumination from all directions. The LEDs and electronics are fully epoxy-encapsulated for protection against harsh industrial environments. IP69K rating ensures resistance to high-pressure washdown, oil and dust. Rugged aluminium alloy housing with PC cover delivers durability for machine and automation applications. High-quality LED source provides bright, steady, non-strobing light suitable for operator visibility. Available diameters: 50 mm, 70 mm and 100 mm. Certifications: CE, RoHS, UL, ETL, CCC; anti-explosion options available. Warranty: 3 years.

Commercial / logistics

• Item no.: O72
• Payment: EXW / FOB / CNF
• Product origin: China
• Shipping port: Guangzhou / Shenzhen / Shanghai
• Lead time: 5–7 days

Technical table
Item name: IP69K 70 mm machine indicator lights
IP rate: IP69K
Color: RYG (Red, Yellow, Green)
LED Life: 50,000 h
Diameter: 70 mm
Material: aluminium alloy housing + PC cover
Connector: M12 or 0.5 m cable
Accessories: Universal bracket
Voltage: 24 V DC
OEM: Welcome

Caractéristiques / spécifications techniques

• Model: O72
• Diameter: 70 mm
• IP rating: IP69K
• Color options: Red, Yellow, Green (RYG)
• LED life: 50,000 hours
• Material: Aluminium alloy housing with PC cover
• Connector: M12 connector or 0.5 m cable
• Accessories: Universal bracket
• Voltage: 24 V DC
• Certifications: CE, RoHS, UL, ETL, CCC (and others)
• Warranty: 3 years
• Features: Epoxy-encapsulated electronics, waterproof, oil-proof, dust-proof, rugged construction, uniform dome illumination
