Explosion-proof loudspeaker DOLSPK

industrial

Overview
CAN/RS485/IO type signal loudspeaker, model DOLSPK. Combined audible and visual alarm with integrated speaker and strobe light, designed for industrial safety and signalling in lifting, port, transportation and manufacturing environments.

Features

• Supports MP3 and WAV audio formats
• Up to 255 programmable playback segments; input trigger to start and disconnect trigger to stop playback
• Volume adjustable by front knob or remotely via RS485/CAN protocol; maximum sound level: 100 dB
• Operating voltage: 15 V DC – 36 V DC
• Audible and visual alarm functions compatible with fire alarm controllers and manual alarm buttons

Application

• Overhead cranes and travelling cranes
• Lifting and construction machinery
• Ports, docks and logistics facilities
• Iron, steel and metallurgical plants
• Security and industrial signalling systems

Additional product information
Available with multiple certification options (CE, RoHS, UL, ETL, CCC). Explosion-proof variants offered for hazardous-area installations. Control interfaces: CAN, RS485, discrete IO.

Shipping / Logistics
Item no.: DOLSPK-CAN type
Product origin: China
Shipping ports: Guangzhou / Shenzhen / Shanghai
Lead time: 5–7 days

Caractéristiques / Spécifications techniques

• Model / Series: DOLSPK
• Supported audio formats: MP3, WAV
• Playback segments: up to 255
• Volume control: front knob and RS485/CAN protocol
• Maximum sound level: 100 dB
• Operating voltage: 15 V DC – 36 V DC
• Alarm types: audible (speaker) and visual (strobe light)
• Typical applications: cranes, ports, transportation, manufacturing, security systems
• Certifications: CE, RoHS, UL, ETL, CCC; explosion-proof options available
• Warranty: 3 years
