Stainless steel annular suction ring

for the pharmaceutical industryfor the food industryfor the metallurgical industry

Rate: 150 to 400 m³/h. Implementation: on reactor, tank, drum... Objectives: to allow easy emptying of small, easy-to-handle packagings, without dust emission. Palamatic Process dedusting rings, in standard or custom sizes, are perfectly adapted to your working environment and the materials handled. Pouyès rings are dust collectors intended for loading tanks, reactors or cylindrical containers. Dust collection rings preserve the operator's working environment by capturing particles and volatile molecules as close as possible to the emission source. • Filling, hopper discharging, sack filling • Reactor loading • Weighing, drum filling • Crushing mill, sieving • Mixings and samples • Simplified ring for vacuuming around the periphery of a vertical mixer • Drum clamping by the ring for filling operations • System connected directly to the reactor to introduce the raw material. Removable system for pressurizing the reactor • Dust removal from the workstation Equipment advantages - No obstruction of the working area, direct access for loading - Protection of the operator's respiratory tract against dust emission - Ergonomics of the workstation thanks to the bag holder - Rapid connection to all types of equipment, removable and cleanable system
