Peelle’s Fast Cab is easy to install – entirely from inside the car. The walls and canopy are 22 in. (56mm) wide by 14 gauge (2mm) thick steel panels, combining ruggedness with easy handling and assembly. All panels have 3/8 in. (10mm) slotted holes, eliminating the need for different sized hardware. Markings are on each panel that note the panel location and sequence for fast and error-free installation.
Standard Cab Enclosure Features
14 gauge (2mm ) steel walls and canopy
Car to frame anti-sway stabilizers
Hinged emergency exit panel with safety contact
Pre-punched gate rail mounting holes
Car operating station cut-out with reinforcement angles
Baked powder coat finish
LED light fixtures
NEMA 1 (IP10)
Cab enclosure uses 3/8 in. (10mm) hardware
Optional Cab Enclosure Features
Stainless steel construction
12 gauge (2.7mm) or thicker walls and canopy
NEMA 4 (IP 54/56), NEMA 4X (IP 56), NEMA 7/9
Wood or steel bumpers
Exhaust fan
Car top safety rail
