Plywood pallet Pave

polypropylenefor industrytransport

Product overview
PERI Pave production pallets are engineered for concrete block and heavy concrete product manufacturing. The latest generation combines a wear-resistant polypropylene coating with a multiplex hardwood core to deliver uniform vibration behaviour, high load-bearing capacity and low net weight. An integrated release effect in the coating reduces concrete and stone residue accumulation, improving uptime in continuous production environments.

Surface & structure

• Integrated release effect in the plastic coating reduces concrete and stone residue buildup.
• Polypropylene coating developed for concrete block production with high impact and abrasion resistance.
• Multiplex hardwood core produced by cross-bonding high-quality veneers from sustainably managed forests.
• Construction provides uniform vibration transmission while keeping low own weight.

Applications

• Production of heavy concrete products (e.g. large paving units, kerbstones).
• Manufacture of elements requiring exceptional flatness and dimensional consistency.
• Use in high-humidity environments such as air-conditioned curing chambers.
• Production of washed concrete products.

PERI Pave in action
The low net weight of PERI Pave panels reduces energy consumption during handling and transport through the machine cycle. Eliminating withdrawal plates in many processes can shorten cycle times and increase throughput.

Improve the longevity of your PERI Pave panels
PERI Pave ReLife is a professional recoating service that renews the functional surface of the panels, extending service life and enabling cost-effective reuse while maintaining performance.

Maintenance & repair

• Regular cleaning and care extend service life; the integrated coating reduces cleaning effort and adhesion of residues.
• Use brushes with plastic bristles to remove concrete and acrylic residues quickly and thoroughly.
• Minor mechanical damage to the panel surface can be repaired on site with the PERI Pave repair kit.

Product Data Sheet — Tabular data
Nominal thickness: 24 – 53 mm
Format: Max. 1500 x 3600 mm
Weight: About 740 kg / m³ with wood moisture of about 12%
