Round tube connector GS16A4E21-24plasticPEPVC
Add to favorites
Compare this product
Characteristics
- Structure
- round
- Material
- plastic, PE, PVC, ABS, EPDM, PP, thermoplastic, steel, stainless steel
- Other characteristics
- anti-vibration
- Diameter
Max.: 290 mm
(11.417 in)Min.: 21 mm
(0.827 in)
Description
PEWOGRIP PN 25 TENSION-PROOF with EPDM Sealing -30°C up to +125°C in A4 (316/1.4571) Quality Ø min./max.Width 45 mm 1 Closure
Important information:
Follow the installation and disassembly instructions.
PN = Working pressure with consideration of the application loads for industrial applications. In case of shipbuilding applications, PN is one PN class below, e.g. PN 25 Industry = PN 16 Shipbuilding.
PN classes = PN 2.5; PN 6; PN 10; PN 16; PN 25
Test pressure = PN x 1.5
The pressure data is given under the precondition that radially rigid steel pipes with a minimum wall thickness are used under static load.
Use the Technical Manual for other pipe materials.
Band inserts are necessary for special applications.
Support sleeves must be used for thermoplastic plastic pipes (PE/PP/PB/PVC/ABS...).
