Cartridge filtration unit FILTRO2x series
oildieselmobile

cartridge filtration unit
cartridge filtration unit
cartridge filtration unit
Add to favorites
Compare this product

Characteristics

Technology
cartridge
Designed for
oil, diesel
Other characteristics
mobile
Filtration size

10 µm

Flow rate

1.5 m³/h, 3 m³/h (52.972 ft³/h)

Description

Descriptive Technical data: Trolley with vane pump Cartridge filter: 10 microns Suction and discharge kit: Oil: 50 to 500 cSt (mm2/s) Built-in and adjustable bypass Maximum suction lift: 5 metres Maximum temperature of the pumped liquid: 60°C Single-phase motor Voltage: single-phase 230 (FiLTRO20, FiLTRO22) and three-phase 400 (FiLTRO21, FiLTRO23) Current: 4.6 (FiLTRO20), 2.2 (FiLTRO21), 7.8 (FiLTRO22), 5 (FiLTRO23) Orifice Ø: 1" Power: 0.75, 1.6 (FJEV22), 2 (FJEV23) Max. TDH: 60 metres (FiLTRO20, FiLTRO21), 50 metres (FiLTRO22, FiLTRO23) Specifications and advantages: Mobile filtration unit with single filter Characteristics More Information FLUID Diesel, Oil TECHNOLOGY Vane ATEX No PUMP Equipped PUMP SETS kits or draining units MAX FLOW RATE 1,5 m3/h max - 3 m3/h max ORIFICE 1" MATERIALS Cast-iron MECHANISM Delrin
