3-axis CNC machining center PWM-50IIverticalgantrycolumn type
Add to favorites
Compare this product
Characteristics
- Number of axes
- 3-axis
- Spindle orientation
- vertical
- Structure
- gantry, column type
- Spindle mount
- BT 50
- Number of tool stations
- 40 tools
- Associated functions
- milling, drilling, tapping
- Applications
- for the automobile industry, for the aerospace industry
- Other characteristics
- high-precision, high-rigidity
- X travel
800 mm
(31.5 in)- Y travel
900 mm
(35.43 in)- Z travel
800 mm
(31.5 in)- Rotational speed
6,000 rpm
(37,699 rad.min-1)- Power
20.4 kW
(27.74 hp)- Work feed X-axis
24 m/min
- Work feed Y-axis
24 m/min
- Work feed Z-axis
24 m/min
- Positioning accuracy
0.012 mm
(0.00047 in)- Repeatability
0.008 mm
(0.00031 in)- Tool-changing time
5.5 s
- Weight
14 t
(15.43 us ton)- Overall length
3,050 mm
(120.1 in)- Overall width
6,900 mm
(271.7 in)- Overall height
3,450 mm
(135.8 in)
Description
1.The machine integrates functions of milling, boring, drilling (drilling reaming,expanding),tapping,etc.
2.The international CNC numerical control system is adopted.
3.The main machine adopts the advanced T-shaped body structure, gantry column,hanging-structured spindle box, with high rigidity, high precision retention,suitable forrough machining and finish machining of precise box parts.
4.It is widely used in the automotive, rail transit,aerospace, valves, mining machinery and other machinery industries.
TOOL MAGAZINE -
Type - / -
Chain-type
AXIS FEED RATES -
X/Y/Z-Axis Cutting feed rate -
mm/min
15000
COVER -
Machine protection - /
Full enclosure with top cover
Slideway protection - /
Roll-up cover
MECHANICAL SPECIFICATION -
Required pneumatic pressure - kg/cm² - 6
cnc system - / -
SIEMENS 828D
