concrete moisture meter / with digital display / relative humidity / portable
Hygropin

{{requestButtons}}

Characteristics

  • Measured material:

    for concrete

  • Other characteristics:

    with digital display, portable, relative humidity

Description

The Hygropin Concrete Moisture Tester is a hand held portable device for determination of relative humidity inside the measuring sleeves embedded into the concrete. The instrument measures humidity and temperature of the two channels (in-situ probe inside the concrete and ambient probe) and uses those values for calculating dew point and tracking trend for each parameter. The Hygropin can assess moisture content in hard concrete, as well as monitor moisture in fresh concrete.

Overview
Your Benefits
Exceeding industry standard requirements
Rapid response time
Unaffected by concrete composition

Measured Quantity
Relative humidity [%RH] and temperature [°C, °F]

Accuracy
Humidity: ± 1.5 % RH Temperature: ± 0.3 K

Applications
•Moisture content assessment on hard concrete
•Moisture content monitoring on fresh concrete

Features
Instrument Firmware Moisture meter shows trend indicators for each parameter
PC Software HygroLink
Display Pixel graphic LCD
Memory 10'000 readings
Measuring Range •Humidity: 0 to 100 % RH
•Temperature: -40 to 85 °C (-40 to 185 °F)
Probe / Sensors •Highly integrated sensor with only 5 mm / 0.3” diameter
•The two independent sensors channels of the moisture meter can measure ambient and concrete characteristics simultaneously
