Motorized roller shutter

extruded aluminumroll upgalvanised steel

Description
The slatted roller shutter is the ideal option to make full use of the available opening while occupying minimal lintel depth. These shutters are manufactured using the latest extruded aluminium technology, offering excellent weather resistance and high security. They can be customized in appearance to suit retail stores, commercial premises or industrial entrances. The component design ensures stable opening and closing operation with reliable sealing.

Applications and advantages

• Suitable as closure for industrial entrances, commercial premises and retail storefronts.
• High-quality materials and extruded aluminium technology for improved durability against weathering.
• Customizable finishes to integrate with commercial or architectural environments.
• Good watertightness and stability in opening and closing movements.

Optional equipment

• Option to insert polyurethane foam as thermal insulation.
• Possible incorporation of vision panels and ventilation grilles.
• Various opening systems: radar, photocells, pull handle, etc.
• Finishes: lacquered metal, lacquered or anodized aluminium, stainless steel.

Available colours

• RAL 9011
• RAL 8019
• RAL 7031
• RAL 7022
• RAL 6005
• RAL 6002
• RAL 9010
• RAL 3000
• RAL 1013
• RAL 8014
• RAL 5010

Frequently asked questions (summary)

• Is it suitable as a security door? Yes, it is considered a secure enclosure and can be used in both industrial and commercial environments, adapting aesthetically to the space.
• Is the roller shutter manual? It can be either manual or motorised. For approximate dimensions from 3 x 3 m, automation is recommended due to weight and handling.
• Is it suitable for intensive use? It is not the best option for very high numbers of daily openings; motorisations of this type are designed for moderate use (e.g. 4–10 openings/day). For frequent-operation applications, a high-speed door is recommended.

Characteristics / technical specifications

• Use: exterior.
• Wind resistance: class 2.
• Main material: extruded aluminium.
• Slat thickness: 1.5 mm.
• Aluminium side guides.
• End pieces in AISI 304 stainless steel, 1 mm thick.
• Galvanised shaft tube, steel pulleys and spring steel band.
