Automatic screwing machine 7483K

stationaryXYZ axis

Product name
Desktop screwing machine

Models
ET7383K / ET7383K-C
ET7483K / ET7483K-C
ET7583KYA / ET7583KYA-C

Key specifications (by model)
Motor control axes: 3 Axes (ET7383K, ET7483K) / 4 Axes (ET7583KYA)
Overall power: 300 W (ET7383K, ET7483K) / 400 W (ET7583KYA)
Moving range X/Y: 300×300 mm / 400×400 mm / 500×400 mm
Moving range Z: 100 mm (all models)
Moving speed X/Y: 0.1–1000 mm/sec (all models)
Moving speed Z: 0.1–300 mm/sec (all models)
Repeat accuracy X/Y/Z: ±0.01 mm (all models)
Platform loaded weight: 8 kg (all models)
Work area: 260×270 mm / 360×370 mm / 460×370 mm
Overall dimensions (W×D×H): 650×590×810 mm / 750×690×810 mm / 820×690×810 mm
Machine weight: 68 kg / 75 kg / 95 kg

Note
Models with "-C" use air-blow screw feeding; models without "-C" use air-suction screw feeding.

Technical features / specifications

• Desktop screwing solution available in multiple footprint sizes to fit different workpieces
• Selectable 3-axis or 4-axis motor control to match assembly complexity
• High repeatability: ±0.01 mm on X/Y/Z axes
• Platform capacity: 8 kg for small-to-medium assemblies
• Wide X/Y speed range (0.1–1000 mm/sec) and Z speed up to 300 mm/sec for cycle-time tuning
• Three work-area configurations and matching machine footprints for process flexibility
• Two screw-feed options: air suction (standard) and air blow (-C variant)
