Truck-mounted binder sprayer AKERA 19H

truck-mounted binder sprayer
truck-mounted binder sprayer
truck-mounted binder sprayer
truck-mounted binder sprayer
truck-mounted binder sprayer
truck-mounted binder sprayer
truck-mounted binder sprayer
truck-mounted binder sprayer
truck-mounted binder sprayer
truck-mounted binder sprayer
truck-mounted binder sprayer
truck-mounted binder sprayer
Add to favorites
Compare this product


Characteristics

Options
truck-mounted

Description

Tank capacity: 19m3 with exterior reinforcement. Adaptable tank on different cahier type (truck; e.g. dumpers, caterpillars, farm tractor trailers, etc.) New zero dust filling system saves 5 to 7 minutes on loading time. Transfer of the binder by 2 worms Ø 460 mm in ROBALON material: the Rabaud signature for 30 years. Variable spreading width from 0.62 to 2.48 m: 4 sections or 15 combinations. High spreading precision: Dosing in a single pass from 3 to 59 kg/m² with a longitudinal variation coefficient of < 5% and < 3.5% in 90% of treatments. Alveolar rotor Ø 440 mm: Lg 2.48m made up of 4 spreading sections controlled from the driver's station. New control terminal with a large 12" touch screen and button controls. Progressive metering spreader with O-CONTROL system as standard: electronically controlled honeycomb rotor. The AKERA 19E is the only spreader on the market to be certified by an independent state reference body for its spreading accuracy. TP articulated frame with high crossing capacity. Central articulation Ø 590 mm by roller slewing ring. Engine: VOLVO PENTA TAD 883 VE - 320 hp turbo diesel (complies with the stage 5 anti-pollution standard in force). Spreading speed from 2.3 to 6 km/h. 100% mechanical transmission for simplicity and speed. 100% inter-wheel and inter-deck differential lock. Dual braking system: hydraulically controlled disc brakes on all 6 wheels.
