Hammer mill MP series
horizontalstrawgrain

hammer mill
hammer mill
Add to favorites
Compare this product


Characteristics

Technology
hammer
Orientation
horizontal
Product applications
grain, straw
Other characteristics
dry milling
Sector
for the food industry
Output

Min.: 1 t/h
(1 lb/s)

Max.: 5 t/h
(3 lb/s)

Motor power

Min.: 30 kW
(40.79 hp)

Max.: 90 kW
(122.37 hp)

Machine length

Min.: 1,290 mm
(51 in)

Max.: 2,530 mm
(100 in)

Machine width

Min.: 900 mm
(35 in)

Max.: 970 mm
(38 in)

Machine height

Min.: 1,100 mm
(43 in)

Max.: 2,060 mm
(81 in)

Machine weight

Min.: 680 kg
(1,499 lb)

Max.: 1,850 kg
(4,079 lb)

Description

Hammer mill is inteded to grind different raw material. Raw material must be dry and clean. Suitable raw material: Straw, length - 1-9cm, humidity no more than 14% Wood chips/sawdust - size no more than 2x2x0,5cm, humidity no more than 11% Peat - humidity no more than 16% Sunflower husk Boon Grainds Bran
