Corrosion protection coating service Lamiplate

wear-resistantprotectiveabrasion-resistant

Short description
It offers anti-corrosive decorative properties and high folding flexibility to the final product.

General

• Excellent flexibility to obtain 0T without cracking.
• Good resistance against scratching. Good resistance to abrasion.
• Pressurised-water cleaning test for 1 hour, 100 bars at 20 cm = no delamination or separations.
• Excellent resistance to chemicals and cleaning products.
• Good resistance to stains. Easy cleaning.
• Excellent resistance to dampness. Inert material, food safe.
• Excellent resistance to mould growth.

Product behaviour
DESCRIPTION | TESTING STANDARD | UNIT | RESULT | OBSERVATIONS
Total coating thickness | EN 13523-1 / ASTM D1005 | µ | 45 |
Specular Gloss (Gardner 60°) | EN 13523-2 / ASTM D523 | % | matte or gloss | depending on film finish
Colour difference | EN 13523-3 / ASTM E1347 | | ΔE ≤ 1 | depending on finish
Pencil hardness | EN 13523-4 / ASTM D3363 | | H – 2H |
Resistant to rapid deformation | EN 13523-5 / ASTM D2794 | joules | 18 | without detachment
Adherence after Erichsen cupping | EN 13523-6 / ASTM E643 | mm | 8 | without detachment
T Bending | EN 13523-7 / ASTM D522 | | 0T | without cracking or separation
Resistance to salt spray | EN 13523-8 / ASTM B117 | hours | > 500 | 2 mm max. detachment
Resistance to accelerated Xenotest ageing test | EN 13523-10 / ASTM D6695 | hours | > 1000 | variable depending on film and design
Resistance to MEC friction test | EN 13523-11 / ASTM D5402 | DF | > 150 | <1
Stain resistant (strawberry, orange, butter, fried tomato, mustard, lipstick, oil, milk, coffee, tea, chocolate, and soap) | EN 13523-18 / ASTM D1308 | | stain free | after 24 hours

Technical specifications

• Commercial name: Lamiplate
• Brand: Replasa Advanced Materials
• Properties: decorative and anti-corrosion; high folding flexibility.
• Flexibility: 0T without cracking.
• Mechanical resistance: good resistance to scratching and abrasion; pencil hardness H – 2H.
• Adhesion: Erichsen cupping 8 mm without detachment.
• Impact resistance: 18 J without detachment (EN 13523-5 / ASTM D2794).
• Total coating thickness: 45 µ.
• Gloss: matte or gloss depending on film finish.
• Colour difference: ΔE ≤ 1 depending on finish.
• Corrosion resistance: salt spray > 500 h (max. 2 mm detachment).
• Ageing resistance: Xenotest > 1000 h (variable depending on film and design).
• MEC friction test: DF > 150, wear < 1.
• Stain resistance: stain free after 24 h for common stains.
• Pressure-water cleaning resistance: 1 h at 100 bar at 20 cm without delamination.
• Chemical resistance and ease of cleaning: excellent.
• Hygiene: inert material, food safe; excellent resistance to dampness and mould growth.
• Industry applications: Domestic Appliances.
