Tracked carrier

wheeledliftingfor containers

• Dimensions : Length : 12.200 mm Width : 2.500 mm Wheel base : 8.140 mm • Chassis : Its made from ST-52 and high resistant “I” cut chassis. 8 mm thickness chassis up and down 14 mm width for the 14 mm 120 mm • Axles : 3 axles with TUV certificate. 1st axle lifting and valve for operation of lifting axle • Suspension : Air suspension on the 3 axles • Air system : WABCO with EBS • Shock absorber • Brake Adjusters : Automatic brake adjusters • King-pin : JOST brand 2” with its protection cover • Landing Legs : 24 ton double speed mechanic landing legs and it has TUV certificate. Air spring heavy duty type 150X150 • Twist locks : 12 units twist lock and they have TUV certificate. 12 units twist locks for 1 unit 40” container or 2X20” container or 1X20” container on the middle of container chassis. Twist locks’ places painted and pins will be galvanized to be seen at night. • Wheel and tyres : 385 65 R 22.5 Bridgestone brand 7 units tyres and rims with TUV certificate • Electrical System : 24 V electrical system with side lamps led every 2.5 Meter – It has ADR certificate • Connectors 15 and 7 pin – 2 unit stop lamp by 7 functionally shall be covered with cage installed by bolts. • 2 units import plate illumination lamp • Reflectors and velocity plates (European type) • Paint : Epoxy and paint with RAL code of customer choice and accessories will be with RAL num
