Full automation
High
Large self-tapping torque range
High flexibility
Size Code - 16
Suitable Screw - M1.0-M2.0
Suitable Screwdriver Bit - 801 Hex Bit / 801 Cross Bit
Outer Dimensions (mm) - 189x60x61
Rated Torque (mN.m) - 500
Torque Accuracy (mN.m) - 10
Torque Display Resolution (mN.m) - 6
Maximum Rotation Speed (r/Min) - 3000
Direction of Rotation - Clockwise, Counterclockwise
Angle Display Resolution (°) - 0.1
Torque Ramp-up Time (s) - 0.01-1
Operation Mode - Three Modes (Universal Mode, Self-tapping Mode, High-speed Mode)
Control Method - Closed-loop Control
Rotary Homing - Sensor
Operating Noise (db) - <70
Rated Voltage (V) - DC 24±10%
Rated Current (A) - 5.69
Peak Current (A) - 17
Weight (kg) - 1.35
