GPS repeater GNSS-L1G1GA

GLONASSBeiDouGALILEO

ROGER GALILEO/GPS/GLONASS/BEIDOU repeater operates by receiving satellite signals with an antenna located outside the building and re-radiating the signals to the indoor area or covered space. Use of re-radiated signals indoors means that GALILEO/GPS/GLONASS/BEIDOU receiver is tracking the current status and signal from the satellites. When a GALILEO/GPS/GLONASS/BEIDOU receiver is moved from covered area to outdoors and vice versa, the receiver is instantly tracking the location instead of time consuming acquisition. Key Features • Automatic gain limitation • Oscillation prevention with indicator • Maximal coverage for CE approved repeater • Sustaining GPS L1/GLONASS G1/GALILEO E1/ BEIDOU B1 fix when moving from indoors to outdoors • Full product family with repeaters, amplifiers and splitters Technical information Frequency: GPS L1 (1.57542 GHz), GALILEO E1 (1.57542 GHz), GLONASS G1 (1.602 GHz), BEIDOU B1 (1.5611 GHz) Size: 200*89*39 mm Weigth: 290 g Overal Gain: > 40 dB Adjustable Gain: 0-40 dB Impedance: 50 Ohm Input connector TNC-female Operating temperature: - 40 - +75 °C Power supply: +12VDC/300mA Indoor coverage: upto 50 meters Antenna power output: + 5 VDC, 100 mA TX antenna gain: max. +4dBd, RHCP polarisized
