DC gear-motor SN3VH
three-phasewormright angle

DC gear-motor
DC gear-motor
DC gear-motor
Add to favorites
Compare this product

Characteristics

Motor type
DC, three-phase
Type
worm
Shaft orientation
right angle
Power
100 W...500 W
Torque
10 - 20 Nm
Voltage
230 V, 400 V
Other characteristics
compact, hollow-shaft, maintenance-free, single-stage, IE2, IE1, aluminum frame, 4-pole, IP54, IP55
Product applications
for industrial applications, for the food industry, for the packaging industry, for hygienic applications, for conveyor systems

Description

The right drive solution for every challenge: The SN3VH-gearmotors impresses with its compact dimensions and flexible application range. The geared motors are available as three-phase or direct current versions and can be equipped with brakes or pulse generators (on request). SN3VH-gear types: SN3VH - Motor types: AC (230/400V) and DC (180/200V) - Shaft design: Ø14 Hollow shaft - Ratios: 5; 7; 11; 15; 17; 20; 24; 30; 32; 38; 56; 75 - Power: 120-250W - permissible torques: 11-17 Nm - effectiv torques: 3,2-23 Nm - Additional options: brake motors, UL/CSA-certification, thermal protection, encoder Additional Data: - Ball bearings for motor and gear - Worms hardened and ground - Wormwheel made of special bronze alloy For further information see product detail page.
