crawler crane / boom / lattice / construction
SCC1000E

{{requestButtons}}

Characteristics

  • Configuration:

    crawler

  • Structure:

    boom, lattice

  • Operating environment:

    construction, building, for marine applications

  • Other characteristics:

    hydraulic, lifting, loading, for heavy-duty applications

  • Lift capacity:

    Max.: 100 t (110 us ton)

    Min.: 15 t (17 us ton)

  • Working height:

    Max.: 61 m (200'01")

    Min.: 0 m (0'00")

Description

Sany SCC1000E crawler crane's maximum lifting capacity is 100 tons, with multifunctional boom system, the crane may support a combination of up to 11 types of operating conditions. The 100 ton crawler tower suits for various business requirements.

Superior Performance
Powerful Lifting Capacity
The maximum lifting capacity of main boom is 360t·m (100t×3.6m), fixed jib 192t·m (8t×24m), luffing jib 210t·m (15t×14m), and the single pull line of main and auxiliary winches is 9.2t.
Excellent Operation
Advanced micro-movement and compound actions ensure smooth and stable operation.
Safety and Reliability
Safe Control System
Switch between the operation and installation modes ensures the safety, and the crane's functions including integrated control display system, emergency electric control, and closed-circuit monitoring are highly convenient and reliable.
Reliable Function Guarantee
Sufficient safety margin in structural design; the control system runs stably even in extreme weather. Advanced hydraulic technology is also adopted to ensure system stability and reliability
High Return & Low Cost
Optimized Transportation
With telescopic crawler, the maximum transport weight of whole machine with track frame and boom tip is 43t, ensuring it to be transported freely.
Convenient Maintenance
It takes no more than 10min/person to adjust, 30min/person for daily maintenance and 2h/person to repair the machine. GPS remote monitoring system is optional for maintenance and management.
