Low headroom manipulator Liftronic® Easy

electricwith gripping toolfor tires

Product description
The Liftronic® Easy Linear Manipulator is designed to handle offset loads in work areas with limited headroom. Its rigid arm reaches loads not accessible from above and allows precise pick-and-place operations in compact spaces while keeping the operator outside the immediate load zone.

Main features

• Automatic weight sensing and continuous automatic load balancing
• High precision in load placement with no impact on the part
• Touch-sensitive handle for fingertip control and stepless speed regulation (very fast to very slow)
• Electronic control that prevents sudden upward movement in case of load loss
• Compact, rigid arm suitable for low-ceiling environments
• Easy to maintain with remote servicing capability

Galleries
Photo gallery illustrating multiple installations, configurations and end-effectors for the Linear Manipulator. Video gallery with product demonstrations and application examples.

Video titles on the page

• Seat handling in cabin
• Linear Manipulator
• Intelligent Lift Assist Device - Linear Version
• INDEVA Linear Manipulator handling tires

Case histories / applications (examples shown on the page)

• Handling tire rims in confined areas
• Exhibition and field demonstrations (e.g. MOTEK)

Technical documentation
Technical data sheet (PDF) available for the Linear Manipulator version.

Technical characteristics / specifications

• Designed for offset/excentric loads in low-ceiling work areas
• Rigid arm to reach loads displaced from the manipulator and operator
• Suitable for compact and limited spaces
• Touch-sensitive handle for precise manual positioning and speed control
• Automatic weight sensing and electronic load balancing
• Automatic balancing control to avoid sudden movements on load loss
• Easy maintenance and remote servicing capability
• Example capacity shown in illustrations: 160 kg (reference LM160L-2F)
