Analog output weight transmitter eNod4-T DIN

EthernetDIN rail mount

Weighing transmitter ±500 000 d, 1 600 meas/s   • Presentation on rail DIN housing • Legal metrology certification according to OIML R76, R51, R61 • Up to 8 strain gauge load cells • Load cell failure detection device • Programmable digital filters • 2 digital inputs (4 with IO+ option) and 4 outputs • Analog output 0-10V or 4-20mA (IO+ option) • 1 USB port for setting by PC • Version with RS485/CAN PLC output and MODBUS-RTU, CANOpen or PROFIBUS-DP protocols • Version with double-Ethernet output ad MODBUS-TCP, EtherNet/IP, EtherCAT or PROFINET protocols • Integrated web server for monitoring and remote setting • 1 RS485 for optional eNodTouch touch screen panel • Optional Bluetooth communication
