Compressed air filter
dustcartridgehigh-capacity

compressed air filter
compressed air filter
compressed air filter
compressed air filter
compressed air filter
compressed air filter
Add to favorites
Compare this product


Characteristics

Designed for
compressed air, dust
Filtration element
cartridge
Other characteristics
high-capacity
Operating pressure

10 bar (145.038 psi)

Flow rate

Max.: 500 m³/h (17,657.333 ft³/h)

Min.: 200 m³/h (7,062.933 ft³/h)

Description

Three times the fil­ter area with the same con­struc­tion vol­ume Com­pared to fil­ter ver­sions with round tubes, car­tridge fil­ters of­fer three times the fil­ter area with the same con­struc­tion vol­ume, en­abling a re­duc­tion in in­vest­ment and op­er­at­ing costs. Car­tridge fil­ters are typ­i­cally used as in­take fil­ters for cen­tral com­pressed-air sys­tems and in bag­ging and pack­ag­ing plants used, for ex­am­ple, in the plas­ter and dry mor­tar man­u­fac­tur­ing in­dus­try. Pipe car­tridge fil­ters are the pre­ferred choice when de­dust­ing low vol­u­met­ric flows (200 to 500 m3/​h) with fine, free-flow­ing and ex­tremely dry dusts in ad­di­tive si­los, bag­ging sta­tions and man­ual dosers. The pres­sure shock-proof ver­sions (10 bar) are the per­fect so­lu­tion for pre-hop­per de­dust­ing in pneu­matic con­veyor sys­tems. Safety fil­ters with a car­tridge fil­ter de­sign are used for pro­tect­ing com­po­nents con­nected down­stream of a main fil­ter (such as com­pres­sors). As a re­sult, these units are also pro­tected in the event that larger quan­ti­ties of dust en­ter the clean gas stream in the main fil­ter be­cause of dam­age to the tube, for ex­am­ple.
