Stainless steel cable clamp C series

polyamidewith screw mountUV-resistant

Around installation technology, cable clamps for the fastening of HF cables to telecommunication masts are our speciality. These cable clamps consist of a C frame including retaining feet (for installation on to a C-profile or flat bar) and a fastening screw with grouted thrust washer. In addition, the corresponding number of cable trays (inlays) are supplied. C frame The C frames are stamped bent parts which – depending on their size – have lateral pieces to provide rigidity and stability. The fixing screws have a uniform hexagon head. Due to the construction and material selection, after tightening, a secure hold is ensured even without a lock nut. A torque of 1.5 Nm is recommended here. Installation to flat bars is possible up to a material thickness of 9.3 mm. Inlay The cable troughs are chamfered for side installation or simple setting into the C frame. The wide overlap protects against falling through before tightening the fastening screw. Naps at the contact surface to the cable ensure a secure hold. The respective sizes are inserted into the inlay radius in metric and imperial. The inlays are available in black and signal grey (RAL 7004). Technical benefits of our cable clamps Torque approximately 1.5 Nm Uniform hexagon head, just one tool Simple handing, as the upper inlay is connected Trusted, secure hold even without counter nut Chamfered inlays for fast, simple application Wide overhang of the inlays to prevent falling Size information in the inlay for better recognition Cable clamps consist of a C frame including retaining feet for the installation on to a C profile or flat bar and a retaining screw with grouted thrust washer
