Half-height turnstile SCT310

They are products designed for controlled access in areas with mass personnel and visitor entrances, such as trade centers, public buildings, metro and train lines, schools, and banks. These products are also manufactured to prevent unauthorized entries, ensuring a long lifespan and are suitable for industrial storage. OPERATION Adjustable manual switching in both directions body 1.2 mm thick stainless steel. Optional: Electrostatic powder coating with different color options. 1.2 MM THICKNESS Power Supply 110/220V – 50/60 Hz AC (%10 +-) Handles Ø 38 MM Electrostatic powder coating with Ø38 mm diameter stainless steel or different colour options IP CLASS IP 54 Op. IP56 Operating Temperature Between (-20°C) and (+68°C) Op: with -50°C heater Functions Switching time adjustable, adjustable switching directions, memory mode, audible alarm Emergency In case of all kinds of disasters and emergencies, the handles run idle. Power Consumption 24V DC standby 12W max 60W 7W max 14W. Power supply system (SMPS) with the feature of filtering fluctuations likely to occur in electrical lines Transition Range 510mm Safety Level High Security Indicators Bidirectional double colour led panel Accessories Heater, battery unit, led spot lighting, dry contact or systems that can be controlled by any voltage between TTL CMOS 5-48V. Control System Compatible with all kinds of Access control units and token systems. Opt. Functions can be controlled with RS232-485 or LAN (network).
