Compatible with 1 phase 2 wire, 3 phase 4 wire systems
Single Channel, Plug-n-wire current transformer input
60 to 300V AC (L - N), 104 to 520V AC (L - L) measurement
Accuracy of ± 0.5% for voltage & current, 0.1% for Frequency, 1% for Power and energy, 0.01 digit for PF
Auxiliary Supply of 60 to 300V (L-N), Self powered
Max Demand measurement for Power
Pulse output and RS485 Modbus communication
CE, MID Certified
Specifications
Display Type - LCD with Backlight
Display Configuration - 1 Rows of 4 Digits, 2 Row of 7 Digits
Electrical Connection - 3Ø – 4W, 1Ø - 2W
Type of Output - 2 Pulse Outputs
Features - Split Load RJ45 Connector Current Input, Self-Powered, Energy (Active / Reactive), Max Demand Of Power
Communication Protocol - RS485 and MODBUS RTU
CT Primary - 5A to 10kA (Programmable for Any Value)
CT Secondary - 330mV
PT Primary - 100V to 10kV (Programmable for Any Value)
PT Secondary - 100V to 500V AC (L - L) (Programmable for Any Value)
Rated Input Voltage - 60 to 300V AC (L - N), 104 to 520V AC (L - L)
Supply Voltage - 60 to 300V AC, 45/65Hz, Self Supplied (V1, V) (45/65Hz)
Size - 70 x 90mm
Mounting Type - Din Rail Mount
Certification - CE
