Crawler crane 824 G
boomhandlingloading

Crawler crane - 824 G - SENNEBOGEN Maschinenfabrik GmbH - boom / handling / loading
Crawler crane - 824 G - SENNEBOGEN Maschinenfabrik GmbH - boom / handling / loading
Crawler crane - 824 G - SENNEBOGEN Maschinenfabrik GmbH - boom / handling / loading - image - 2
Crawler crane - 824 G - SENNEBOGEN Maschinenfabrik GmbH - boom / handling / loading - image - 3
Crawler crane - 824 G - SENNEBOGEN Maschinenfabrik GmbH - boom / handling / loading - image - 4
Crawler crane - 824 G - SENNEBOGEN Maschinenfabrik GmbH - boom / handling / loading - image - 5
Crawler crane - 824 G - SENNEBOGEN Maschinenfabrik GmbH - boom / handling / loading - image - 6
Crawler crane - 824 G - SENNEBOGEN Maschinenfabrik GmbH - boom / handling / loading - image - 7
Crawler crane - 824 G - SENNEBOGEN Maschinenfabrik GmbH - boom / handling / loading - image - 8
Crawler crane - 824 G - SENNEBOGEN Maschinenfabrik GmbH - boom / handling / loading - image - 9
Crawler crane - 824 G - SENNEBOGEN Maschinenfabrik GmbH - boom / handling / loading - image - 10
Add to favorites
Compare this product

Characteristics

Configuration
crawler
Structure
boom
Applications
handling, loading
Engine type
diesel engine
Other characteristics
compact, electric
Load

10,000 kg
(22,046.2 lb)

Working height

Max.: 12 m
(39'04" )

Min.: 10 m
(32'09" )

Horizontal reach

12 m
(39'04" )

Driving speed

20 km/h
(12.4 mph)

Crane engine power

118 kW
(160.4 hp)

Drive engine power

90 kW
(122 hp)

Width (base)

3,455 mm
(136 in)

Length (base)

4,450 mm
(175.2 in)

Total weight

26,300 kg
(57,982 lb)

Description

THE MULTI-​TALENT IN THE RECYCLING AND SCRAP YARD The SENNEBOGEN 824 G material handler is universally applicable in the field of recycling and scrap handling with its reach of 12 m. In the demanding work environment, the robust machine convinces with maximum performance despite low consumption and is a master in any loading and sorting task. The elevating comfort cab ensures a pleasant, safe workplace with an excellent view of the work area. The 824 G is also available as a battery-powered variant. Coordinated modular diversity You get a SENNEBOGEN machine that is perfectly matched to the requirements of your application - thanks to the modular design: Can be equipped with different grippers or a magnet Compact boom or boom with deflection mechanism, e.g. for sorting grabs Several undercarriage options, e.g. with 4-point undercarriage, with different pylon heights Also available as battery-powered variant: work emission free! MAXIMUM EFFICIENCY & PERFORMANCE Rely on great system performance for maximum efficiency at high handling speeds. The efficient SENNEBOGEN diesel engine generation with automatic idle stop saves you operating costs thanks to lower consumption. Monitor energy consumption and utilization through the intuitive SENCON control system. Achieve outstanding efficiency with optimized hydraulics. The SENNEBOGEN 824 G offers the best accessibility to all components via stairs and ladder. LONG-LASTING INVESTMENT Benefit from long-term value retention of the machine, even during demanding continuous operation: Intelligent machine design and robust components enable a long service life for your machine.
