Working range
Blind rivet nuts from M3 up to M10 all
materials as well as M12 in aluminium and steel
Technical data
Weight: 2.4 kg
Adjustable stroke,max: 10mm
Adjustable traction force, max: 18,5 kN at 5 bar
Operating air pressure: 5-7 bar
Air hose connection: 6 mm Ø (1/4’’)
Air consumption: approx. 2 to 4 ltr. per
rivet nut
(depending on
nut size)
Scope of delivery
2 double open ended wrenches SW 24/27
1 hexagon screw driver SW 4
1 oil refi ll can with hydraulic oil 100 ml
1 oil refi ll can
Operating instructions with spare parts list
