Electric forklift SFD50stand-onhandlingcounterbalanced
Add to favorites
Compare this product
Characteristics
- Motor type
- electric
- Operator
- stand-on
- Applications
- handling
- Other characteristics
- 4-wheel, counterbalanced
- Carrying capacity
5,000 kg
(11,023.1 lb)- Lifting height
4,429 mm
(174.37 in)- Overall width
3,110 mm
(122.4 in)- Overall length
4,180 mm
(164.6 in)- Load center distance
500 mm
(19.7 in)- Weight without load
Min.: 3,030 kg
(6,680 lb)Max.: 4,160 kg
(9,171.2 lb)- Seat height
1,280 mm
(50.4 in)- Fork carriage width
1,380 mm
(54.3 in)- Lifting speed
Min.: 40 mm/s
Max.: 490 mm/s
- Lowering speed
Min.: 21 mm/s
Max.: 380 mm/s
- Gradeability
20 %
- Noise level
91 dB, 96 dB
Description
Configuration selling point
The core components, including the transmission and drive axle, are self-manufactured and meticulously matched with the dedicated engine, resulting in not only low fuel consumption but also substantial traction.
Ease of maintenance and operation comfort
The machine features a removable suspension frame, allowing for easy maintenance. It is equipped with an intelligent diagnostic system. The wide-view door frame and adjustable safety seat provide a comfortable driving and riding experience and convenient operation.
Adaptability to diverse working conditions
Optional door frames and forks with varying configurations are available, ensuring robust load capacity to accommodate different logistics conditions.
Wheelbase(mm) - 2250
External dimensions - 4737×1995×2500
Load center distance(mm) - 600
Front overhang(mm) - 622
Forward/Backward Tilting Angle of Gantry(°) - 6°/12°
Emissions (Indicated as per international standards) - EU stage ⅢA
