Electrical power supply connector

wire-to-wireclick-lockwith 2 pins

Product summary
20A quick-lock waterproof connector for security systems and landscape lighting, featuring IP67 protection and silver-plated copper contacts for stable power transmission.

Overview

• 20A Current Capacity – 20A rated current with silver-plated copper pins for stable power transmission.
• Quick Lock Mechanism – Tool-free QuickLock connection with audible click feedback and anti-vibration locking.
• IP67 Waterproof – Fully sealed against water and dust for outdoor and industrial use; suitable for temporary immersion.
• Security Systems Ready – Designed for CCTV cameras, security monitoring equipment and landscape lighting installations.
• Global Certifications – ISO9001, CE, UL, TUV and RoHS certified.

Specifications (table)
Product Details | Specification 1 | Specification 2 | Specification 3
Pin number: 2 Pin | 3 Pin | 4 Pin
Pin diameter X number: 2.4mm | 2.4mm | 2.4mm
Current rating: 20A | 20A | 20A
Voltage rating: 300V | 300V | 300V
Withstanding voltage: 2000V | 2000V | 1500V
Cable Gauge: 0.75mm²–2.5mm² (20–12AWG) | 0.75mm²–2.5mm² (20–12AWG) | 0.75mm²–2.5mm² (20–12AWG)
Diameter Range: MAX Φ13.0mm | MAX Φ13.0mm | MAX Φ13.0mm
Protection Level: IP67 | IP67 | IP67
Connecting mode: QuickLock | QuickLock | QuickLock
Prevent the combustion level: UL94-V0 | UL94-V0 | UL94-V0
Operating temperature: -40°C – 105°C | -40°C – 105°C | -40°C – 105°C
Certification: ISO9001, CE, UL, ROHS | ISO9001, CE, UL, ROHS | ISO9001, CE, UL, ROHS

Product details
This MJ20 series family uses silver-plated copper contacts to ensure stable power transmission. The tool-free QuickLock mating provides audible click feedback and anti-vibration locking for secure field connections. The flame-retardant housing meets UL94-V0. Models are sealed to IP67 for outdoor deployment including temporary immersion and dust protection. The connectors accept a broad cable gauge range (0.75mm²–2.5mm², 20–12 AWG) with maximum cable diameter up to Φ13.0mm. Operating temperature range is -40°C to 105°C. Quality and safety certifications include ISO9001, CE, UL and RoHS.

Technical specifications

• Series: MJ20
• Model variant: 3-Pin
• Current rating: 20A
• Voltage rating: 300V
• Withstanding voltage: 2000V
• Pin diameter: 2.4mm
• Cable gauge: 0.75mm²–2.5mm² (20–12 AWG)
• Maximum cable diameter: Φ13.0mm
• Protection: IP67 (waterproof & dustproof)
• Connecting mode: QuickLock (tool-free, audible click)
• Contact material: silver-plated copper pins
• Housing: UL94-V0 flame-retardant material
• Operating temperature: -40°C to 105°C
• Certifications: ISO9001, CE, UL, RoHS
