Lithium-thionyl chloride battery ER142501/2AA typecylindrical3 V
Add to favorites
Compare this product
Characteristics
- Type
- lithium-thionyl chloride
- Configuration
- 1/2AA type, cylindrical
- Voltage
- 3 V
- Applications
- for automotive applications, industrial
- Standard
- ISO, CE, UL, UN 38.3, IEC
- Other characteristics
- primary, high-capacity, extended temperature range
- Load capacity
1.2 Ah
- Length / diameter
14.5 mm
(0.6 in)- Width
14.5 mm
(0.57 in)- Height
25 mm
(1 in)
Description
Key Features
Battery Description
Features
Applications
Storage Conditions
Warning
Specifications / Technical Characteristics
- Voltage: 3.6V
- Nominal Capacity: 1200mAh
- Dimension: 1/2AA Size-14.5×25.0mm
- Shelf Life: 20 Yrs
- Operating Temperature: -60-85℃
- Max Discharge Current: 30 mA (continuous), 50 mA (Pulse)
- Applications: Electric power/water/gas meters, Memory ICs, and IOT Devices.
- Certified By UN38.3, CE, UL, ISO9001
Battery Description
- Leading Lithium Battery Factory. Competitive Price, Flexible MOQs. Free Sample Available.
Features
- High Energy Density up to 590Wh/kg
- Wide Operating Temperature Range -60℃~+85℃
- Low Self-Discharge Rate: ≤1%/Year during 25℃ storage
- Extended Storage Life: 10+ years under room temperature conditions.
- Hermetic Glass-to-Metal Sealing: Provides enhanced safety and durability.
- Non-Flammable Electrolyte: Increases safety during usage.
- Compliance with IEC86-4 Safety Standards
- Safe for Export: UN38.3, CE, UL, ISO9001
Applications
- Smart Meter
- Alarms and Security
- Memory Backup Power
- GPS
- Automotive Electronics
- IoT Devices
Storage Conditions
- Store in a clean, cool environment (preferably below +20℃, not exceeding +30℃).
- Ensure the area is dry and well-ventilated.
Warning
- Non-rechargeable: These are non-rechargeable batteries.
- Safety Hazards: Fire, explosion, and burn hazards associated with improper handling.
- Do Not: Recharge, short circuit, crush, disassemble, heat above 100℃, or incinerate.
- Temperature Range: Do not use the battery beyond the permitted temperature range.
Specifications / Technical Characteristics
- Voltage: 3.6V
- Nominal Capacity: 1200mAh
- Dimension: 1/2AA Size-14.5×25.0mm
- Shelf Life: 20 Years
- Operating Temperature: -60-85℃
- Max Discharge Current: 30 mA (continuous), 50 mA (Pulse)
- High Energy Density: up to 590Wh/kg
- Low Self-Discharge Rate: ≤1%/Year at 25℃
- Extended Storage Life: 10+ years at room temperature
- Hermetic Glass-to-Metal Sealing
- Non-Flammable Electrolyte
- Compliance: IEC86-4, UN38.3, CE, UL, ISO9001
