--Integrated Intel® 1037U 1.8GHz dual-core CPU TDP17W
--Intel® NM70 high speed chipset
--1* SO DDRIII Memory Slot ,Support 1066/1333 Memory, Max. up to 8GB
--Intel® HD Core graphics, Providing VAG / HDMI display output
--1* 2.5’SATA place
--1* MSATA , Supports SSD / WIFI
--Integrated 1* (RTL 8111E Chip) Gigabit LAN,Supports Wake-on-LAN
--1* Mini-PCIE,supports WIFI /3G Module
--6* COM
--6* USB 2.0
--1* PWR Switch
--1* LAN
--1* VGA
--1* HDMI
--1* DC_12V IN
--1* WIFI antenna port
--Full enclosed and fanless ,cooling by chassis
--Dimension :214*200*50 (L*W*H/mm)
--DC_12V single power input
--Desktop or wall mounting
--Sandblasting oxidation process (Black)
Model No. -
MINI-PC-AIO-C1037UC6S3
Motherboard -
ITX-AIO-C1037UC6S3
CPU -
Integrated Intel® 1037U 1.8GHz dual-core CPU TDP17W
Chipset -
Intel® NM70 high speed chipset
System Memory -
1* SO DDRIII Memory Slot ,Support 1066/1333 Memory, Max. up to 8GB
Graphics -
Intel® HD Core graphics, Providing VAG / HDMI display output
Storage -
1* 2.5’SATA
1* MSATA , Supports SSD / WIFI
Network -
Integrated 1* (RTL 8111E Chip) Gigabit LAN,Supports Wake-on-LAN
Wireless Network -
1* Mini-PCIE,supports WIFI /3G Module
Front Panel Port - 1* COM
2* USB 2.0
1* PWR Switch
1*Line out 1* Mic port
Rear Panel Port -
5* COM
1* Line out(green) 1* Mic (red)
4* USB 2.0
1* LAN
1* VGA
1* HDMI
1* DC_12V IN
1* WIFI antenna port
