Office workstation KKKF25EPLUS

for medical applicationswith collaborative robots

Overview

• Floor space: 2.1 m²
• Equipment size (W×D×H): 1600×1300×2010 mm (excluding top light box)
• Net weight: 650 kg
• Production time: 90–120 seconds per cup
• Capacity per refill: 150 cups

Workstation parameters
Category: Basic parameters
Equipment model: KKKF25EPLUS
Floor space: 2.1 m²
Equipment size: 1600 × 1300 × 2010 mm (excluding top light box size)
Net weight: 650 kg
Communication: Network cable / WiFi / SIM traffic card
Payment methods: WeChat / Alipay
Production time: 90–120 seconds per cup
Number of cups per refill: 150 cups
Cup sizes: Cold cup 500 ml (89 × 55 × 130 mm); Hot cup 380 ml (89 × 55.7 × 118 mm)
Input voltage / power: AC 220V/50Hz, 4 kW
Tablet: 10.1 in.
Milk refrigeration: 0 to 4 °C
Coffee categories: Americano (hot/cold), Latte (hot/cold), Cappuccino, Raw Coconut Latte (cold), Caramel Latte (hot/cold), etc.

Cobot arm parameters

• Maximum effective load: 3 kg
• Maximum end speed: 1.0 m/s
• Maximum linear speed at end: 0.8 m/s
• Effective working radius: 618 mm
• Repeatability: ±0.02 mm
• IP rating: IP54 / IP65
• Communication: TCP/IP, Modbus/TCP, Profinet, EtherNet/IP
• Degrees of freedom: 6
• Joints (J1–J6) range: ±360° each
• Maximum joint speed: 225°/s
• Tool interface: GB/T14468.1-50-4-M6
• End connector I/O: 2 digital I/O, 24V, 0.6A
• Power source: 100–200 VAC, 47–63 Hz, 10 A
• Typical power consumption: 200 W
• Installation: any orientation
• Operating ambient temperature: -10 °C to 50 °C
• Storage temperature: -40 °C to 55 °C

Technical specifications

• Model: KKKF25EPLUS
• Size: 1600 × 1300 × 2010 mm (excluding top light box)
• Floor space: 2.1 m²
• Net weight: 650 kg
• Production time: 90–120 s per cup
• Capacity per refill: 150 cups
• Supported cup sizes: Cold 500 ml (89 × 55 × 130 mm); Hot 380 ml (89 × 55.7 × 118 mm)
• Workstation input power: AC 220V/50Hz, 4 kW
• Tablet: 10.1 in.
• Milk refrigeration: 0–4 °C
• Cobot payload: 3 kg; Reach: 618 mm; Repeatability: ±0.02 mm
• Cobot IP rating: IP54 / IP65
• Communications: Network cable / WiFi / SIM traffic card; Cobot: TCP/IP, Modbus/TCP, Profinet, EtherNet/IP
• Payment: WeChat, Alipay
• Operating ambient temperature: -10 °C to 50 °C
• Storage temperature: -40 °C to 55 °C

Applications

• Scenic spots, office buildings, shopping centers, cinemas
• High-speed rail stations, airports, commercial streets
• 5-star hotels, hospitals and other public or commercial venues
