4-color flexographic press L444-150 TC-CE

for plastic filmfor paperweb

Product overview
L444-150 TC-CE is a full automatic four-colour flexographic printing press with 150 mm print width. It is designed for automatic 4‑colour printing of adhesive tape, end-of-sleeve application and automatic packing of printed tape onto sleeves. Capable of printing PVC, OPP (pre-treated, solvent, hot-melt, acrylic water & solvent based) and adhesive paper.

Advantages

• Easy & friendly digital control panel
• Electronic meter counter
• Electronic web tape guide
• Tape cutting at selected lengths (max roll length handling up to 132 m): 48 mm, 50 mm, 72 mm, 75 mm

Key features

• 4 colours
• 4 drums through which the tape passes for printing
• Multiple setting device by razor blades
• Automatic change of the log roll with tape cut & attach
• Corona treatment (optional) with ventilation/suction system
• Electronic web guide for tape alignment
• Heated ceramized cylinder with adjustable temperature
• 4 printing stations equipped with metal screened rollers & printing cylinders
• Drying hot air tunnel between each printing station with push & suction air system
• Double horizontal ventilation/suction tunnel for colour drying
• Cliché cylinders with lengthwise and axial register adjustment (helicoidal teeth)
• Main drying hot air tunnel with thermoregulator
• Automatic paper tab attachment
• Air blower for tape cooling before slitting
• 3 rewinding mandrels, 3″ diameter
• Automatic cutting at the end of the roller with tab positioning checkout
• Automatic rewinding mandrel discharge after cutting and positioning of the new core
• Safety guards with limit switches to stop the machine when opened
• External touch screen control panel with adjustable temperatures, speeds and machine outputs

Options

• Automatic core loader
• Ceramized screened rollers

Technical specifications

• Type: Fully automatic four-colour flexographic printing press
• Model: L444-150 TC-CE
• Print width: 150 mm
• Colours: 4
• Printable substrates: PVC; OPP (pre-treated, solvent, hot-melt, acrylic water & solvent based); adhesive paper
• Tape cutting: selectable lengths 48 mm, 50 mm, 72 mm, 75 mm; max roll length handling up to 132 m
• Drums: 4 drums through which the tape passes for printing
• Roll handling: automatic change of log roll with tape cut & attach; automatic rewinding mandrel discharge and new core positioning
• Rewinding mandrels: 3″ diameter (three mandrels)
• Drying: hot air tunnel between printing stations; main drying hot air tunnel with thermoregulator; double horizontal ventilation/suction tunnel for colour drying
• Cylinder: heated ceramized cylinder with adjustable temperature; 4 printing stations with metal screened rollers and printing cylinders
• Registration: cliché cylinders with lengthwise and axial register adjustment (helicoidal teeth)
• Web handling: electronic web guide for tape alignment; electronic meter counter
• Tape cooling: air blower before slitting
• Safety: safety guards with limit switches to stop the machine when opened
• Control: external touch screen control panel for temperature, speed and output adjustments
• Optional: corona treatment with ventilation/suction system
